VS Deep Well Jet Pump Series

  • Nema J dual voltage motor features copper windings, double ball bearings and overload protection with automatic reset
  • Precision-molded impeller and diffuser insures perfect alignment and ultra-smooth passages for high performance and reliability
  • View More Details

Introducing the VS Deep Well Jet Pump Series, featuring adjustable diaphragm pressure for maximum capacities and pressure at all times.

1
year limited
warranty
Categories: Brand:
1
year limited
warranty

Have a question? Give us a call!

877-710-7867
VS Deep Well

Introducing the VS Deep Well Jet Pump Series, featuring adjustable diaphragm pressure for maximum capacities and pressure at all times.

Product Details

Introducing the VS Deep Well Jet Pump Series, engineered to deliver optimal performance and reliability for your water pumping needs. The VS series features a two-stage design with adjustable diaphragm pressure, ensuring maximum capacities and consistent pressure levels at all times. Its NEMA J dual voltage motor boasts copper windings, double ball bearings, and overload protection with automatic reset, enhancing durability and efficiency.

Designed for precision and longevity, the pump includes a precision-molded impeller and diffuser that ensure perfect alignment and ultra-smooth passages, contributing to high performance and reliability. The large one-piece pump case design allows for easy disassembly without disturbing the well or discharge pipes, simplifying maintenance and servicing tasks.

With its top-located priming port and discharge, the pump prevents air lock and enables easy priming, ensuring hassle-free operation. Additionally, convenient tappings are provided for draining the pump and installing pressure switches and pressure gauges, further enhancing usability and versatility.

Backed by a 1-year limited warranty, the VS Deep Well Jet Pump Series offers peace of mind and reliability, making it an ideal choice for various residential and commercial applications where dependable water pumping is essential.

Features and Benefits
  • Large one-piece pump case design, pump can be disassembled without disturbing well or discharge pipes
  • Top-located priming port and discharge prevents air lock and allows for easy priming
  • Convenient tappings for draining of pump and installation of pressure switch and pressure gauge
  • 1 year limited warranty
Product Specifications

Motor:

3/4, 1, 1-1.2 HP

Hertz:

60 Hz

RPM:

3450 RPM

Volts:

115 or 230 V

Phase:

1 Ph

Stages:

1 and 2 Stage

Impeller Type:

Precision-molded
