Commander 3 VFD

  • Compatible with 3-wire 4" submersible motors/above ground motors
  • Output Phase: Single/Three Phase
  • View More Details

The Commander 3 VFD offers advanced compatibility with 3-wire 4″ submersible and above-ground motors, supporting both single and three-phase outputs. Its features include a quiet composite enclosure, efficient cooling and ventilation, and intuitive controls for easy adjustments. The robust NEMA 3R enclosure, premium heatsink, and spacious terminal blocks ensure reliable performance and straightforward installation.

Categories:

Have a question? Give us a call!

877-710-7867
front view of the Commander 3 while open
Commander 3 VFD

The Commander 3 VFD offers advanced compatibility with 3-wire 4″ submersible and above-ground motors, supporting both single and three-phase outputs. Its features include a quiet composite enclosure, efficient cooling and ventilation, and intuitive controls for easy adjustments. The robust NEMA 3R enclosure, premium heatsink, and spacious terminal blocks ensure reliable performance and straightforward installation.

Product Details

The Commander 3 VFD builds on advanced engineering and user-centric design, offering compatibility with 3-wire 4″ submersible motors and above-ground motors, with single and three-phase output. Its composite enclosure ensures quiet operation, while the hinged cover, side-mounted ventilation, and full-size cooling fan provide optimal airflow and temperature control. The robust NEMA 3R enclosure and premium heatsink guarantee protection and efficient heat dissipation. Drive status indicator lights and easy-to-read DIP switches simplify adjustments, and the intuitive dial allows precise underload sensitivity and pressure control. Quality terminal blocks with ample wiring space streamline installation, making the Commander 3 VFD a versatile and reliable choice.

Features and Benefits
  • Quality terminal blocks with spacious wiring area
  • Compatible with both pressure transducer and switch
  • Convenient dial for precise underload sensitivity and pressure adjustment
  • Settings adjustment DIP switches with large easy to read diagram
  • Drive status indicator lights
  • NEMA 3R enclosure with premium heatsink
  • Full size cooling fan for maximum air flow and temperature control
  • Side mounted ventilation
  • Hinged cover for easy access
  • Composite enclosure for quiet operation
Product Specifications

Model #:

CMDR3

HP:

1/2 to 2HP

Motor Type:

3-wire 4" submersible motors/above ground motors

Output Phase:

Single/Three Phase

Max Output Current:

13.2

Input Voltage:

230 +/- 10% VAC

Pressure Settings:

Pressure sensor: 25-80psi / Transducer: 10-90% of range
