Détails du produit
CANDIDATURES
- Sewage lift stations.
- Housing developments.
- Low-pressure sewer systems.
- High vertical lift or long force mains.
POMPE :
- 440 stainless steel cutter and plate hardened to Rockwell C55-60.
- Discharge size – 2-1/2″ flanged horizontal adaptable to 3″ flange, 2″ NPT optional.
- Seals – dual mechanical carbon/rotary ceramic/stationary, Buna-N elastomers.
- Moisture detection system.
- Construction – Cast iron ASTM A-48, Class 30, 30,000# tensile strength, protected with a corrosion-resistant, baked-on epoxy powder coating.
- Balanced concentric pump housing and impeller.
- Attaching hardware – 304 stainless steel.
- Square ring seals – Buna-N.
- Impeller – Ductile iron vortex design.
- En option :
- Turbine ajustée
- Silicon carbide seals
- 50′ (15.2 m) power cord and sensor cables
- Joints à bague carrée en Viton
- 2″ NPT discharge (high head and high flow models only)
- High flow
- Automatic reversing (3 Ph flanged models only)
- Non-sparking rail systems
MOTEUR :
- cCSAus rated Class I, Division 1, Groups C & D and Class Zone 1, Groups IIA & IIB Construction
- Tested to FM standards 3600 and 3615 by CSA
- Stator – Class F insulation and lead wires. NEMA B design.
- Thermal sensor and leads.
- Housing – cast iron, oil-filled.
- Ball bearings – upper and lower high carbon chromium steel.
- Power and sensor cable length: 25′ (7.6 m).
Note : Les informations sur les produits présentées ici reflètent les conditions au moment de la publication. Consulter l'usine en cas de divergences ou d'incohérences.
